Le SHACMAN M3000 truck telescopic crane, produced by CSCTRUCK Tow Crane, is a robust and versatile lifting machine designed for demanding tasks. Featuring an 8×4 drive type, this crane ensures excellent stability and maneuverability on various terrains. It boasts a substantial rated lifting moment of 35 metric tonnes(mt) and can handle a rated lifting capacity of 14,000 kilograms at a 2.5-meter outreach, making it suitable for heavy-duty operations.
With a maximum outreach of 18.1 mètres, le SHACMAN M3000 can extend its capabilities to significant distances, facilitated by its 5 boom sections. La grue’s boom can be raised from 0 à 75 degrés, reaching a maximum lifting height of 20.5 mètres. The basic boom length is 5.6 mètres, which can be fully extended to 18.5 mètres, allowing for flexible lifting solutions.
Le truck telescopic crane is equipped with a fully extended outrigger span of 7,250 millimeters, enhancing stability during operations. It also features an all-rotation continuous slewing angle, providing seamless 360-degree rotation for precise placement of loads. The hook can handle up to 6 lines, increasing lifting efficiency.
The hydraulic system of the SHACMAN M3000 is designed for high performance, with a recommended volume of 100 liters per minute and operating pressure ranges of 29/32Mpa. The oil tank has a capacity of 200 liters, ensuring sustained operation without frequent refills.
Overall, le SHACMAN M3000 truck telescopic crane par CSCTRUCK Tow Crane is a highly capable and reliable piece of equipment, ideal for various lifting and construction applications.
CARACTÉRISTIQUES
1. High Lifting Capacity and Reach: The crane has a rated lifting capacity of 14,000 kg at a 2.5-meter radius and a maximum outreach of 18.1 mètres, making it suitable for heavy lifting tasks over considerable distances.
2. Advanced Boom Configuration: It features a 5-section boom with a basic length of 5.6 meters and a fully extended length of 18.5 mètres. The boom can be raised from 0° to 75°, providing flexibility in handling various lifting operations.
3. Robust Lifting Mechanism: The crane boasts a rated lifting moment of 35 metric tons (mt) and can achieve a maximum lifting height of 20.5 mètres, supported by a maximum of 6 lines on the hook for enhanced lifting stability and strength.
4. Efficient Hydraulic System: The hydraulic system operates at an optimal pressure of 29/32 Mpa, with a recommended volume of 100 liters per minute, ensuring smooth and powerful crane operations. It also features a large 200-liter oil tank capacity for extended operation without frequent refueling.
5. Stability and Control: The crane is equipped with a fully extended outrigger span of 7,250 mm, providing excellent stability during lifting operations. It also offers continuous 360-degree rotation for precise positioning and improved maneuverability on job sites.
SPÉCIFICATION
| Basic data | CSCTTC1404-2 | CSCTTC1405-2 |
| Moment de levage nominal | 35 mt | 35 mt |
| Capacité de levage nominale | 14,000 kg (2.5 m) | 14,000 kg (2.5 m) |
| Max. outreach | 15 m | 18.1 m |
| Max. lines of the hook | 6 | 6 |
| Slewing angle (continuous) | All Rotation | All Rotation |
| Boom raising angle | 0~75° | 0~75° |
| Max. lifting height (the measurement from the ground after the outriggers are fully extended) | 17.1 m | 20.5 m |
| Length of the basic boom | 5.5 m | 5.6 m |
| Length of fully extended boom | 15.4 m | 18.5 m |
| Boom sections | 4 | 5 |
| Outrigger span (fully extended) | 6,000 mm | 7,250 mm |
| Recommended volume for the system | 100 L/min | 100 L/min |
| Operating pressure | 29/32 Mpa | 29/32 Mpa |
| Oil tank capacity | 200 L | 200 L |
