BRIEF
FEATURES
SPECIFICATION
Basic Information | |
Drive form | 4X2 |
Wheelbase | 4700mm |
Body dimensions | 9.185×2.42×2.85 meters |
Total mass | 15.8 tons |
Vehicle weight | 8.35 tons |
Maximum speed | 98km/h |
Front track/rear track | Front:1815mm; rear:1800mm |
Front overhang/rear overhang | 1.43/3.055 meters |
Engine Parameters | |
Engine model | Dongfeng EQH180-52 |
Displacement | 4.752L |
Maximum horsepower | 180 horsepower |
Maximum output power | 132kW |
Fuel type | Diesel |
Emission standard | Euro V |
Mounted Equipment Parameters | |
Mounted equipment brand | Pafit brand |
Lifting capacity | 7255kg |
Transmission Parameters | |
Transmission model | Fast small eight-speed |
Number of gears | 8 gears |
Number of reverse gears | 2 |
Chassis Parameters | |
Chassis brand | Dongfeng Commercial Vehicle |
Chassis series | Tianjin |
Chassis model | DFH1160BX1JV |
Number of leaf springs | 11/11+10, 8/10+8, 3/4+3, 2/3+2 |
Tires | |
Number of tires | 6 |
Tire specification | 9.00R20 16PR |
