Basic Information | |
Drive Type | 8X4 |
Wheelbase | 2100 + 4300 + 1350mm |
Type | Flatbed Transporter |
Vehicle Dimensions | 11.38 × 2.5 × 3.2 meters |
Gross Vehicle Mass | 31 tons |
Rated Mass | 18.065 tons |
Front Overhang/Rear Overhang | 1.47 / 2.16 meters |
Engine Parameters | |
Engine Model | Xichai CA6DL2 – 33E3F |
Displacement | 8.6L |
Maximum Output Power | 249kW |
Maximum Horsepower | 330hp |
Emission Standard | Euro III |
Mounted Equipment Parameters | |
Mounted Equipment Brand | Shenhu Brand |
Other Special Instructions | This vehicle is only used for transporting non-dismantlable objects. The cab can be optionally installed according to the chassis. The side board structure with side boards can be optionally installed, and the height of the side boards is 550mm. The side protection adopts cold-formed channel steel / Q235 – A, and is connected by welding. The rear protection is integrated with the vehicle structure and is replaced by vehicle components. |
Transmission Parameters | |
Transmission Model | Fast 9JS119 |
Number of Gears | 9 – speed |
Chassis Parameters | |
Chassis Brand | FAW Jiefang |
Chassis Series | Jiefang J6 |
Chassis Model | CA3310P66K2L6BT4E |
Rear Axle Description | 7.6T / 16T |
Number of Leaf Springs | 10 / 10 / 12 |
Tires | |
Number of Tires | 12 |
Tire Specification | 11.00R20, 12.00R20, 11.00 – 20, 12.00 – 20 |
