BRIEF
FEATURES
SPECIFICATION
Basic Information | |
Drive form | 4X2 |
Wheelbase | 3860mm |
Body dimensions | 7.51×2.36×2.74 meters |
Total mass | 8.28 tons |
Vehicle weight | 4.82 tons |
Maximum speed | 115km/h |
Front track/rear track | Front track:1640mm; rear track:1590mm |
Front overhang/rear overhang | 1.15/2.5 meters |
Engine Parameters | |
Engine model | Dachai CA4DC2-12E4 |
Displacement | 3.168L |
Maximum horsepower | 124 horsepower |
Maximum output power | 91kW |
Fuel type | Diesel |
Emission standard | Euro IV |
Mounted Equipment Parameters | |
Mounted equipment brand | Chengliwei brand |
Lifting capacity | 3265kg |
Others | The side protection is connected by welding to the longitudinal beam of the chassis. The rear is equipped with a lifting arm device, which has a rear protection function. Optional swing arm flat plate and rear guardrail. |
Transmission Parameters | |
Transmission model | WLY5-35 of Wanliyang |
Number of gears | 5 gears |
Number of reverse gears | 1 |
Chassis Parameters | |
Chassis brand | FAW Jiefang light truck |
Chassis series | Tiger V |
Chassis model | CA1081P40K2L2BE4A84 |
Number of leaf springs | 7/10+3 |
Tires | |
Number of tires | 6 |
Tire specification | 7.50-16 14PR, 7.50R16 14PR, 8.25-16 14PR, 8.25R16 14PR |
