BRIEF
FEATURES
1.Potent Towing Capacity
2.Crane Functionality
3.Durability and Build Quality
4.Safety and Control Systems
5.Versatile Applications
SPECIFICATION
– General Information | |||
GVW | 11600kg | Wheelbase | 4500mm |
Tare Weight | 6600kg | Wheel drive | 4×2 |
Loading | 5000kg | Tires | 7.50R16 |
Front Axle | 2400kg | – Flatbed | Make/Model: CSCTRUCK/5P2 |
Rear Axle | 4200kg | Inner length (mm) | 6300mm |
Length | 8300mm | Inner width (mm) | 2300mm |
Width | 2250mm | Max Load Rating | 5000kg |
Height | 3250mm | Minimum tilt angle | 8° |
Steering | RHD | Maximum lifting capacity at full extension | 2500kg |
Platform working stroke (mm) | 2700mm | ||
– Chassis Truck | Make/Model HOWO 4×2 140 | Platform height from ground (mm) | 1100mm |
Engine | – Flatbed-winch | ||
Make/Model | Cummins/ISF3.8s3141 | Rated traction force (KN) | 50KN |
Type | Diesel | Wire rope diameter | 11mm |
Engine System | 4 Cylinders | Wire length | 25m |
Horsepower | 141HP | Winch diameter | 110mm |
Power/speed | 105kW/2600rpm | Minimum wire rope speed | 5(m/min) |
Displacement | 3.76L | Crane | |
Torque/Speed | 450N.m/1200-2200rpm | Make/Model | XCMG/SQS68 |
Emission | Euro 3 | Maximum lifting capacity | 3200kg |
Transmission | Maximum lifting torque | 67.2kN•m | |
Make/Model | WLY651 | Maximum arm length | 7.82m |
Gears | 6F/1R | Maximum lifting height | 9.8m |
Operation | Manual | Boom length | 3.34~7.82m |
Max Torque | 500N.m | Luffing range | 0~80° |
Synchronizer | YES | Slewing angle | 360° continuous rotation |
Cabin | |||
Cab Model | HOWO cab | ||
Cab Allowed | 3 | ||
Air Condition | YES |
