HOWO Truck 4X2 5.7Ton Mounted Palfinger Crane

HOWO Truck 4X2 5.7Ton Mounted Palfinger Crane

HOWO Truck 4X2 5.7Ton Mounted Palfinger Crane

Chassis Make/Model:	SINOTRUK/ZZ1167N4617B1
Dimensions,mm:	9190×2550×3850
Wheelbase,mm:	5600
G.V.W,kg:	23000
Tare Weight,kg:	10530
F/R Axle Rating,kg:	7000/16000

Truck Enquiry

Category: Knuckle Boom Crane Tag: Mounted Palfinger Crane

Description
Reviews (0)

SUMMARY

The HOWO Truck 4X2 5.7Ton Mounted Palfinger Crane is a highly capable and versatile vehicle.

This truck is equipped with a 4X2 drivetrain, providing good maneuverability and stability on various road conditions. The mounted Palfinger crane with a 5.7-ton lifting capacity is a significant asset, enabling it to handle a wide range of lifting and loading tasks.

The HOWO Truck is known for its durability and reliability, making it suitable for construction sites, logistics operations, and other demanding applications. With its combination of a powerful truck and a high-performance crane, it offers efficient and effective solutions for material handling and transportation needs.

FEATURES

The HOWO Truck 4X2 5.7Ton Mounted Palfinger Crane is a remarkable vehicle with several distinct features:

Powerful Truck Base

The 4X2 configuration of the HOWO truck provides excellent stability and maneuverability. It is designed to handle a variety of road conditions and terrains.
The truck is powered by a reliable engine that offers sufficient horsepower and torque to carry the weight of the crane and perform various tasks.

Impressive Palfinger Crane

The mounted Palfinger crane has a 5.7-ton lifting capacity, making it suitable for a wide range of heavy lifting operations. It can handle loads with precision and ease.
The crane is known for its advanced technology and functionality. It features smooth operation, precise controls, and a wide range of movement, allowing for efficient loading and unloading.

Versatility and Adaptability

This combination of truck and crane is highly versatile. It can be used in construction sites, industrial settings, logistics operations, and more.
The crane can be adjusted and positioned to reach different heights and angles, enabling it to access hard-to-reach areas and perform tasks in confined spaces.

Durability and Reliability

Both the HOWO truck and the Palfinger crane are built to last. They are constructed with high-quality materials and components to withstand heavy use and harsh environments.
Regular maintenance and servicing can ensure the longevity and reliable performance of the vehicle and crane.

Safety Features

The HOWO Truck 4X2 5.7Ton Mounted Palfinger Crane is equipped with various safety features to protect the operator and those around the vehicle.
These may include safety locks, overload protection systems, and warning indicators to ensure safe operation during lifting and transportation.

In conclusion, the HOWO Truck 4X2 5.7Ton Mounted Palfinger Crane is a powerful and versatile vehicle that offers a combination of strength, precision, and adaptability. It is an ideal choice for those in need of a reliable and efficient lifting and transportation solution.

SPECIFICATIONS

Cab Truck		Crane
Chassis Make/Model:	SINOTRUK/ZZ1167N4617B1	Make/Model:	Palfinger/ SPK10000A
Dimensions,mm:	9190×2550×3850	Crane Type	Knuckle Boom Crane
Wheelbase,mm:	5600	Max. lifting moment	9.5mt
G.V.W,kg:	23000	Max. lifting capacity	5700kg
Tare Weight,kg:	10530	Max. hydraulic outreach	12.4m
F/R Axle Rating,kg:	7000/16000	Max.outreach lifting capacity	590kg
Cab		Number of extension boom	2(A),3(B),4(C)
Cab Make/Model:	SINOTRUK/HOWO 7	Slewing angle	400°
Cab Type:	Sleeper Cab, AC	Slewing moment	1.2mt
Cab Width:	2080mm	Max. stabilizer spread	4870mm
Cab Height:	Standard w/o Streamlined Dome	Fitting space required	657mm
Rated Nr. of Passengers:	3 People	Width folded	2500mm
Engine		Max. operating pressure	315bar
Engine Make/Model:	WEICHAI/WP10.300E2	Recommended pump capacity	30-45lmp
Engine Power/Speed:	220kW(300hp)/2200rpm	Dead weight standard crane	1031kg
Output Torque/Speed:	1240N.m/1300-1500rpm	Standard package includes
Displacement:	9.726 L	– Oil tank mounted
Emission Standard:	Tier Level III Emission	– Load holding valves
Transmission		– Painting
Gearbox Make/Model:	SINOTRUK/HW19710	– High pressure filter
Type:	Manual,Forward 10 Speed/Reverse 2 Speed	– Digital hour counter
Clutch		– Load hook
Type:	Single, Dry, Diaphragm Spring	– Crane preservation
Diameter:	φ320mm	– Mounting bolts
Steering		Dropside Platform
Position:	Right Hand Drive	Max Load Rating:	15 Ton, dropside
Type:	Recirculating Ball	Deck Size,mm:	5200*2500,exterior
Axle	Front VGD71,Rear ST16	Construction:	Sheet Metal Forming
Main Brake	Dual-circuit air Braking Booster	Material Thick, mm:	Bottom 5, Side 3
Parking Brake	Acting on axle, Central Drum Brake	Doors:	All dropside open
Suspension		Electrical Equipment
Type:	Semi-elliptical Alloy Leaf Spring with Hydraulic Two-way Telescopic Shock Absorber	Battery:	24V/(Two Batteries in Parallel)
Specifications:	10/9+6H	Starter:	24Volts/2.8kW
Tyre	295/80R22.5,6+1 Nos
Tool Box:	2 nos
