Shacman Road Rescue Towing Truck Wrecker Summary:
Shacman Road Rescue Towing Truck Wrecker is a reliable and powerful vehicle designed for efficient road rescue operations. With a robust chassis and a powerful CUMMINS engine, it ensures top-notch performance. The truck’s 8×4 RHD driving type and MAN axles guarantee stability and control during towing tasks. The Shacman standard cabin equipped with modern amenities provides a comfortable and safe driving experience.
This Shacman Road Rescue Towing Truck Wrecker is a versatile and reliable solution for road rescue and towing operations. Whether it’s on highways or in urban areas, this powerful wrecker is ready to handle any challenging situation with ease and efficiency.
Features:
- Robust Chassis:
The vehicle’s sturdy chassis ensures durability and stability during rescue operations, making it ideal for heavy-duty tasks.
- Powerful Engine:
The CUMMINS ISME420 30 engine with 420HP output ensures high performance and fuel efficiency, meeting Euro3 emission standards.
- Smooth Transmission:
Equipped with a FAST brand manual transmission with 12 forwards and 2 reverse gears, the truck offers precise gear shifting for seamless driving.
- Versatile Towing Capacity:
The Wrecker equipment boasts a maximum towing weight of 50,000 kg, making it capable of handling various vehicle sizes and weights.
- Efficient Lifting System:
The Max. Lifting Weight of 50,000 kg and Max. Lifting Height of 12,000 mm allow for quick and safe vehicle recovery.
- User-friendly Operation:
The Extend-retract of the Lifting Arm and Slope Angle of the Lifting Arm features provide ease of use and enhance maneuverability during rescues.
- Dual Winch System:
With two winches, each rated at 25,000 kg pulling capacity, the truck can handle complex recovery scenarios with ease.
- High-quality Materials:
The 50-meter steel cable with a diameter of 25 mm ensures durability and reliability during towing operations.
- Comfortable Cabin:
The Shacman tow truck standard cabin equipped with air conditioning and one sleeper ensures a comfortable working environment for the operator.
- Safety First:
The vehicle meets all safety standards and offers advanced safety features to protect the driver and others on the road.
Specifications:
| CHASSIS | |||
| Cabin | Driving type 8×4 RHD | ||
| Shacman standard Cabin with one sleeper, Air conditioner equipped; | |||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 11500*2500*3280 | |
| Wheelbase (mm) | 1800+4600+1350 | ||
| Wheel track (front/rear) (mm) | 2012/1738 | ||
| Approach/Departure angle(°) | 16/18 | ||
| Weight in KGS | Tare Weight | 22000 | |
| Axle | Front axle | MAN 9500kgs*2 | |
| Rear axle | MAN 16000kgs*2 | ||
| Max. driving speed(km/h) | 90 | ||
| Engine | Brand | CUMMINS | |
| Model | ISME420 30 | ||
| Type | 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
| Horse Power(HP) | 420HP | ||
| Emission standard | Euro3 | ||
| Gearbox | FAST brand, 12JSDX240T-B, Manual Transmission, 12 forwards & 2 reverse | ||
| Clutch | Reinforced diaphragm clutch, diameter 430m | ||
| Fuel tank (L) | 400L | ||
| Tire | 12R22.5 tubeless tire, 13 pieces including one spare tire | ||
| WRECKER EQUIPMENT | ||
| Max. Towing Weight(kg) | 50000 | |
| Lifting System | Max. Lifting Weight(kg) | 50000 |
| Max. Lifting Height (mm) | 12000 | |
| Extend-retract of Lifting Arm(mm) | 6000 | |
| Slope Angle of Lifting Arm(°) | 5~60 | |
| Winch Rated Pulling Capacity (kg) | 25000*2 | |
| Length of Steel (m) | 50 | |
| Steel Diameter (mm) | 25 | |
